FR4 8 layer PCB- 94V 0 with gold plating process

Categories	Multilayer PCB Manufacturing
Brand	PCBQuick PCB Manufacturing and Assembly
Model	KF-rigid pcb a-11
Base Material	fr4
Copper Thickness	1oz
Board Thickness	1.6mm
Min. Hole Size	0.2mm
Min. Line Width	0.1mm
Min. Line Spacing	0.1mm
Surface Finishing	ENIG
solder mask	green
silk screen	white
certificates	rohs,iso,ul
pcb size	customized
sample time	24hours,48hours,96hours...
delievery time	4-5days
shipping way	DHL,FEDEX...
packing	vacuum packing
Application	electronic
customized	OEM&ODM
Terms of Payment	L/C, D/A, D/P, Western Union, MoneyGram, T/T, Paypal
Download DOC
Update Time	2022-01-17

Detail Information

FR4 8 layer PCB- 94V 0 with gold plating process

Our products:

PCB Made Ability:

Item			Technical Standards
Rise			1-20 Layer
Material			FR-4,CEM-1,CEM-3,Hight TG,FR4 Halogen Free,FR-1,FR-2,Aluminum
Thickness			0.2mm-3.2mm(8mil-126mil)
Minimum thickness			0.075mm(3mil)
Cu			1/2 oz min;5 oz max
Min line width/spacing			0.075mm/0.1mm(3mil/4mil)
Min drill hole			0.2mm(8mil)
Punching the smallest aperture			0.9mm(35mil)
Surface finish/treatment			HALS/HALS lead free,Chemical tin,Chemical Gold,Immersion gold Inmersion Silver/Gold,Osp,Gold Plating
The largest size puzzle			610mm×508mm
Tolerance		Pore spaces	+/-0.075mm(3mil) CNC Driling
		Line width	+/-0.05mm(2mil) or
			+/-20% of original artwork
		Aperture	PTH L:+/-0.075mm(3mil)
			Non-PTH L:+/-0.05mm(2mil)
		Appearance Tolerance	+/-0.125mm(5mil) CNC Routing
			+/-0.15mm(6mil) by Punching
		Warp	0.70%
Insulation Resistance			10Kohm-20Mohm
Conduction Resistance			<50ohm
Test voltage			10-300V
MLB	Interlaminar deviation		4 layers:0.15mm(6mil)max
			6 layers:0.25mm(10mil)max
