FR4 Multilayer PCB Manufacturing with Peelable

FR4 Multilayer PCB Manufacturing with Peelable

FR4 Multilayer PCB Manufacturing with Peelable
FR4 Multilayer PCB Manufacturing with PeelableFR4 Multilayer PCB Manufacturing with PeelableFR4 Multilayer PCB Manufacturing with PeelableFR4 Multilayer PCB Manufacturing with PeelableFR4 Multilayer PCB Manufacturing with Peelable
CategoriesMultilayer PCB
AlbumView larger image
BrandPCBQuick
MaterialFR4
Board Thickness1.6mm
Soldermask ColorGreen
Silkscreen ColorWhite
Surface TechnicsHAL-Free
Min Holes0.2mm
Min Line space and width5/5mil
SoldermaskPeelable
FOB portShenzhen,Hongkong
Terms of PaymentL/C, D/A, D/P, Western Union, MoneyGram, T/T, Paypal
Download DOC
Update Time2019-11-20
Detail Information

FR4 Multilayer PCB Manufacturing with Peelable


Welcome to Kingfung Co.Ltd

    We are a professional PCB manufacturer with 10 years experience.PCB products range single-sided,double-sided and  multilayer PCB,flexible PCB and MCPCB.


Product Description


Material: FR4 multilayer PCB manufacturing
Board Thickness: 1.6mm
Soldermask Color: Green
Silkscreen Color: White
Surface Technics: HAL-Free
Min Holes:0.2mm
Min Line space and width: 5/5mil

Special solder mask: Peelable


FR4 Made Ability


 NO ItemCraft Ability
1

Surface Finishh

HASL,Immersion Gold,Gold Plating,OSP,Immersion Tin,etc
2Layer2-30 layers
3Min. Line Width3 mil
4Min. Line Space3 mil
5Min. Space between Pad to Pad3 mil
6Min.Hole Diameter0.10 mm
7Min. Bonding Pad Diameter10 mil
8Max. Proportion of Drilling Hole and Board Thickness1:12:5
9Max. Size of Finish Board23 inch*35 inch
10Rang of Finish Board's Thickness0.21-7.0 mm
11Min. Thickness of Soldermask10 um
12SoldermaskGreen,Yellow,Black,White,Red,Transparent photosensitive solder mask,Strippable solder mask
13Min. Linewidth of Idents4 mil
14Min. Height of Idents25 mil
15Color of Silk-screenWhite,Yellow,Black
16Date File FormatGerber file and Drilling file,Report series,PADS 2000 series,Powerpcb series,ODB++
17E-testing100% E-Testing:High Voltage Testing
18Material for PCB

High TG Material:High Frequence

(ROGERS,TEFLON,TADONIC,ARLON):Halogen-free Material

19Other TestImpedance Testing,Resistance Testing,Microsection etc
20Special Technological RequirementBlind&Buried Vias and High Thickness Copper




PCB Quality Requirement


1.on-time delivery:≥97%
2.double layer board acceptability≥99%
3.four-layer board acceptability:≥98%
4.six-layer board acceptability:≥97%
5.eight-layer board acceptability:≥97%
6.ten-layer board acceptability:≥95%
7.customer satisfaction :≥90%
8.complaint rate/rejected rate:≤ 3%


PCB Certificates


UL, TS16949, ISO14001, ISO9001-2008, and RoHS
