custom print pcb board with ENIG

custom print pcb board with ENIG

custom print pcb board with ENIG
custom print pcb board with ENIGcustom print pcb board with ENIGcustom print pcb board with ENIGcustom print pcb board with ENIG
CategoriesDouble Sided PCB
AlbumView larger image
BrandPCBQuick
ModelKF-FR4 PCB
Base MaterialFR4
Copper Thickness1oz
Board Thickness2.0mm
Min. Hole Size0.2mm
Min. Line Width0.1mm
Min. Line Spacing0.1mm
Surface FinishingHASL/ENIG
Solder MaskBlack
Silk ScreenWhite
Unit PriceUS $ 60-180 / square meter
Download DOC
Update Time2018-12-10
Detail Information

FR4 2.0mm double-sided pcb board

Layers: 1-20 layer

Material:FR4

Board thickness:1.6mm

Copper Thickness: 35um

Min Holes:0.2mm

Min Line Width and space:5mil/5mil

Slodermask Color:Black

Silkscreen: White,

Surface finish:ENIG

Outline: Routing & V-CUT

Plus Test Point on Technology side


1.Printed Circuit Board Fabricate/Assembly
2.UL,SGS,ROHS Certificated
3.Competitive Price,High Quality
4.OEM Circuit Assembly



Welcome To K.F PCB Factory



We are professional PCB manufacturer with ten years experiences .

Products range-single, double side ,multi-layer PCB ,flexible PCB and MCPCB.

We can provide fast prototype service S/S in 24hrs , 4-8layers in 48-96 working

hrs production time .


1.PCB Made Ability:


Item

Technical Standards

Rise

1-20 Layer

Material

FR4

Board Thickness

1.6mm

Copper Thickness

35um

Soldermask Color

Green

Silkscreen Color

White

Min Holes

0.2mm

Surface Technics

ENIG

Min Line Width and space

5mil/5mil

Outline

 Routing & V-CUT

Tolerance

Pore spaces

+/-0.075mm(3mil) CNC Driling

Line width

+/-0.05mm(2mil) or

+/-20% of original artwork

Aperture

PTH L:+/-0.075mm(3mil)

Non-PTH L:+/-0.05mm(2mil)

Appearance Tolerance

+/-0.125mm(5mil) CNC Routing

+/-0.15mm(6mil) by Punching

   Warp

0.70%

Insulation Resistance

10Kohm-20Mohm

Conduction Resistance

<50ohm

Plus Test Point on Technology side


MLB

Interlaminar deviation

4 layers:0.15mm(6mil)max

6 layers:0.25mm(10mil)max



2.Detailed Terms for Pcb Assembly



Technical Requirement:

1) Professional Surface-mounting and Through-hole soldering Technology

2) Various sizes like 1206,0805,0603 components SMT technology

3) ICT(In Circuit Test),FCT(Functional Circuit Test) technology.

4) PCB Assembly With UL,CE,FCC,Rohs Approval

5) Nitrogen gas reflow soldering technology for SMT.

6) High Standard SMT&Solder Assembly Line

7) High density interconnected board placement technology capacity.



Production Requirement:

1) Gerber file and Bom list

2) PNP Files,clear pics needed for pcba

3) Testing method for products



3.View of PCB(PCBA) Factory



high quality FR4 2.0mm double-sided pcb boardhigh quality FR4 2.0mm double-sided pcb board



high quality FR4 2.0mm double-sided pcb boardhigh quality FR4 2.0mm double-sided pcb boardhigh quality FR4 2.0mm double-sided pcb board
